LONA

Solar Lighting System

for Parks, Sidewalks and Cyclepaths

Integrated (All-In-One) System

From 40W to 100W

Manufactured in accordance with EU standards and licensed under the CE certification.

LONA

OFF-GRID SOLAR LIGHTING WITHOUT CABLING & LANDSCAPING COSTS

LONA is a convenient and cost-effective solution for off-grid outdoor lighting applications. The integrated solar powered system is grid-independent and can be easily moved anywhere it is required.

All energy from the sun is stored in lithium battery packs which provides total freedom from electricity bills, uncontrolled grid power fluctuations and blackouts. Low or even negligible maintenance costs, zero carbon emission and zero ongoing energy costs makes LONA model suitable for energy-efficient smart cities.

The LONA have been specifically designed for parks, gardens, sidewalks, cyclepaths and public areas. It provides safe and sustainable LED outdoor lighting at nights as well as in emergencies like power outages, disasters and earthquakes.

LONA can be carried even by one person safely with its lightweight aluminum structure

All-in-one Integrated design of LONA model provides high energy conversion efficiency by combining the LED module, LED driver, solar panel, lithium battery, intelligent controller and communication unit in one setting.

  • null

    NO TRENCHING

  • null

    WITHOUT CABLING

  • null

    MAINTENANCE FREE

  • null

    NO BILLS FOR ELECTRICITY

LONA requires no cabling, trenching, or grid connection which provides significant cost savings and environmental benefits.
SUITABLE FOR IoT APPS WITH DIFFERENT SENSOR GROUPS

LONA designed to work with different types of sensors which collect, store and transfer data to the servers with GPRS connection. LONA uses solar energy as the only power source for data collection and communication.

HIGH QUALITY AND TECHNOLOGY

LONA is the outcome of our commitment to continuous R&D and innovation culture. With our know-how and dedicated team of engineers, we develop and deliver unique solutions with careful consideration of both function and aesthetics in our production plant based in Istanbul, Turkey.

LONA uses high-performance monocrystalline photovoltaic modules for the highest possible energy yields. Our high-quality solar panels can exceed 22% efficiency and integrated intelligent controller based on the MPPT algorithm reaches the energy conversion efficiency of up to 97.4%.

%100 Green Energy, Zero Carbon Emission

Solar-powered REFA-L contributes to the reduction of carbon-emissions.
WIRELESS COMMUNICATION OPTIONS

Remote management system allows you to conveniently manage and monitor LONA with its simple mobile application through wireless communication options (Bluetooth, Wi-Fi, GPRS). Flexible communication hardware also makes it easy to implement additional functions such as WiFi hotspots or various sensors.

LONA can be the backbone of smart cities by integrating wireless connectivity extensions.

Luminaire lighting levels of LONA is dimmable between 1%-100% by using mobile application. Optionally, LONA can store 24 hours’ log information for 2 years.



GENERATION & CONSUMPTION OF ENERGY AT THE SAME UNIT

LONA generates electricity from solar energy during the day and stores it in a battery system. During the night, the energy stored in the battery is used to power the LED luminaires. Thus, Solar LED Lighting system act as a fully independent and autonomous unit utilizing %100 renewable energy.

LONA

MODELS:

REFA L
MODELREFA L300REFA L350
LuminaireZONE – symmetrical 60º -120ºZONE – symmetrical 60º -120º
Lumen4000 lm4800 lm
Color Temperature2200K-6000K2200K-6000K
Protection ClassIP65IP65
BatteryLithiumLithium
Autonomymin. 2 daysmin. 2 days
Working Temperature-20°C  +60°C-20°C  +60°C
Pole Height3m3.5m
Weight21.1kg22.4kg
NEW GENERATION- LONG LIFE LITHIUM BATTERIES

LONA uses lithium battery packs as an energy storage system with 3,000 charge-discharge cycles at 100% DOD. Our advanced lithium batteries can withstand extreme weather conditions with high tolerance to temperature changes. They also have long cycle life with a lifespan of up to 10 years.

New generation lithium based batteries offer significant advantages, including high charge-discharge efficiency, light-weight, capability to deep-cycle, high energy density and low maintenance. They have a working temperature ranging from -20ᵒC to +60ᵒC which can also be expanded to -40ᵒC thanks to our advanced thermal management technology.

Our efficient battery management system is designed to monitor and control the cell balancing actively in order to optimize the charging efficiency and maximize the battery life.

COLOR OPTIONS

We can meet your specific color requirements by using the RAL color system. Any color can be applied to our models with pre-defined RAL code.

DIMENSIONS:
LONA has two standard pole height options as 6m, 8m and 10 meters. However, we can offer custom-designed pole height options specific to your project requirements.

REFA L 300

REFA L 350

LENS TYPES:

We use two types of optical lenses in order to supply optimum light distribution and reduce light pollution. One of the lenses is used for circle shaped zone lighting, while the other is suitable for roads and highways.

LENS TYPE - 1 | PARKS, SIDEWALKS, CYCLEWAYS

  • Material = PMMA Clear, Non-yellowing
  • Full angle at 50% from maximum: ~ 130°
  • Full angle at 10% from maximum: ~ 165°

LENS TYPE - 2 | ROADS, STREETS

  • Material = PMMA Clear, Non-yellowing
  • Full angle at 50% from maximum: ~ 150°x30°
  • Full angle at 10% from maximum: ~ 160°x130°
Manufactured in compliance with CE standards & ISO9001.

  • Parks & Gardens
  • Sidewalks & Cyclewalks
  • Hospital gardens
  • Emergency muster points
  • Streets & Avenues
  • Outdoor lighting for campus & buildings
  • Outdoor lighting for Military areas

  • Solar Panel
  • Battery Group
  • Lighting group
  • Electronic boards
  • Cooling Unit
  • Wireless Communication (Wifi/Bluetooth/GPRS) (Optional)
  • Motion Sensors (Optional)
  • Climate Sensors (Optional)
  • Pole & rack equipment

  • From 10W to 35W LED Options
  • Wireless Communications Options (Bluetooth/Wi-Fi/GPRS)
  • Mobile Application – Android
  • Color Options with RAL codes
  • Sensor Groups
