İLKA - FiPRONET Elektronik İmalat

iLKA

Solar Lighting System

for Highways, Streets & City Main Roads

with Comprehensive Configuration Options

From 30W to 100W

Manufactured in accordance with EU standards and licensed under the CE certification

iLKA

HIGH POWERED OFF-GRID SOLAR LIGHTING SOLUTION

iLKA Solar Lighting System is the ideal solution for highways, city streets, urban roads, industrial and residential areas. It is equipped with highest level of technology to provide high powered bright lighting.

iLKA is an easy to install and cost-effective off-grid outdoor lighting solution that comes with a wide choice of configurations to meet your preferences and performance requirements.

Solar Lighting System has no operating and energy costs and will significantly lower the installation and maintenance costs.

iLKA provides safe and sustainable LED outdoor lighting at nights as well as in emergencies like power outages, disasters and earthquakes. All energy from the sun is stored in lithium battery packs which provides total freedom from electricity bills, uncontrolled grid power fluctuations and blackouts.

iLKA Solar Lighting Pole ranges from 30w to 100w with a high capacity battery allowing maximum autonomy. The solar lighting system is engineered for long-term and reliable performance with the most efficient use of the resources.

iLKA requires no cabling, trenching, or grid connection which provides significant cost savings and environmental benefits.

SENSOR HUB FOR IoT APPLICATIONS

iLKA designed to work with different types of sensors which collect, store and transfer data to the servers with GPRS connection. iLKA uses solar energy as the sole source of power for data collection and communication.

HIGH QUALITY AND TECHNOLOGY

iLKA is the outcome of our commitment to continuous R&D and innovation culture. With our know-how and dedicated team of engineers, we develop and deliver unique solutions with careful consideration of both function and aesthetics in our production plant based in Istanbul, Turkey.

iLKA uses high-performance and high-capacity monocrystalline photovoltaic modules for the highest possible energy yields. Our high-quality solar panels can exceed 22% efficiency and integrated intelligent controller based on the MPPT algorithm reaches the energy conversion efficiency of up to 97.4%.

%100 Green Energy, Zero Carbon Emission

Solar-powered iLKA model contributes to the reduction of carbon-emissions

WIRELESS COMMUNICATION OPTIONS

Remote management system allows you to conveniently manage and monitor iLKA with its simple mobile application through wireless communication options (Bluetooth, Wi-Fi, GPRS). Our flexible communication hardware also makes it easy to implement additional functions such as WiFi hotspots or various sensors for data collection.

Luminaire lighting levels of iLKA is dimmable between 100%-1% by using mobile application. Optionally, iLKA can store 24 hours’ log information for 2 years.

GENERATION & CONSUMPTION OF ENERGY IN THE SAME UNIT

iLKA generates electricity from solar energy during the day and stores it in a battery system. During the night, the energy stored in the battery is used to power the LED luminaires. Thus, Solar LED Lighting system act as a fully independent and autonomous unit utilizing %100 renewable energy.

iLKA

MODELS:

iLKA

MODEL	iLKA 400	iLKA 600	iLKA 800
Luminaire	ROAD/ZONE 60º -120º	ROAD/ZONE 60º -120º	ROAD/ZONE 60º -120º
Lumen	6000 lm	9600 lm	12800 lm
Color Temperature	3000-6000K	3000-6000K	3000-6000K
Protection Class	IP65	IP65	IP65
Battery	Lithium/GEL	Lithium/GEL	Lithium/GEL
Autonomy	min. 2 days	min. 2 days	min. 2 days
Working Temperature	-20°C +60°C	-20°C +60°C	-20°C +60°C
Pole Height	4m	6m	8m
Weight	149 kg	160 kg	186 kg

NEW GENERATION- LONG LIFE LITHIUM BATTERIES

iLKA uses lithium battery packs as an energy storage system with 3,000 charge-discharge cycles at 100% DOD. Our advanced lithium batteries can withstand extreme weather conditions with high tolerance to temperature changes. They also have long cycle life with a lifespan of up to 10 years.

New generation lithium based batteries offer significant advantages, including high charge-discharge efficiency, light-weight, capability to deep-cycle, high energy density and low maintenance. They have a working temperature ranging from -20ᵒC to +60ᵒC which can also be expanded to -40ᵒC thanks to our advanced thermal management technology.

Our efficient battery management system is designed to monitor and control the cell balancing actively in order to optimize the charging efficiency and maximize the battery life.

COLOR OPTIONS

We can meet your specific color requirements by using the RAL color system. Any color can be applied to our models with pre-defined RAL code.

DIMENSIONS:

iLKA has three standard pole height options as 4m, 6m and 8meters. However, we can offer custom-designed models specific to your project requirements.

İLKA 400

İLKA 600

İLKA 800

LENS TYPES:

We use two types of optical lenses in order to supply optimum light distribution and reduce light pollution. One of the lenses is used for circle shaped zone lighting, while the other is suitable for roads and highways.
